1,the winding tube inner diameter: Φ40 - Φ400 r
2,winding paper tube thickness: 1-15mm
3,production speed: 1 to 15 m/min
4,cutting length: 1-4 m
5,cutting way: adopting the single round blade
6,work pressure: 0. 6 mpa
7,host pcwer: 16 kw
|
8,fixed-length patterns: CNC
9,gluing system: make PL type ritiber (standard)
10,paper feeding:configuration ZT (standard) paper
11,the operat:3-4
12,host size:6500*2100*2100
13,machinery (gross weight) : 4350 kg (or so)
|
